| 结构部分 Component parts |
材料名称 Name of material |
规格型号 Specification（mm） |
备注 Note |
|---|---|---|---|
| 基本尺寸 Basic dimension |
外部尺寸 Outer dimensions |
5900*2480*2510 | |
| 内部尺寸 Inside dimensions |
5740*2360*2390 | ||
| 折叠尺寸 Folded Size |
5900*2480*360 | ||
| 底部框架 Bottom frame |
Q235方管 Q235 square tube |
60*140*1.3 | |
| Q235方管 Q235 square tube |
60*80*1.3 | ||
| Q235方管 Q235 square tube |
40*40*1.2 | ||
| 顶部框架 Top frame |
Q235方管 Q235 square tube |
40*80*1.3 | 异型方管 Shaped square tube |
| Q235方管 Q235 square tube |
60*60*1.3 | ||
| Q235方管 Q235 square tube |
40*40*1.2 | ||
| Q235方管 Q235 square tube |
20*20*1.2 | ||
| 3m/6m侧立面（异型钢） 3m/6m side elevation (profiled steel) |
Q235方管 Q235 square tube |
50*70*1.2 | 异型方管 Shaped square tube |
| 板材 Sheets |
地板 Floor |
2855*1177*15 | 防火玻镁板 Fireproof glass-magnesium board |
| 防水屋面板 Waterproof roof |
2520*1000*0.35 | 压型彩钢板 Pressure moulded colour steel plate |
|
| 吊顶板 Suspended ceiling plate |
2340*1000*0.25 | 压型彩钢板 Pressure moulded colour steel plate |
|
| 彩钢板 Colour steel plate |
1150*65/50*0.25 | 50mm/65mm厚EPS复合板/岩棉板 50mm/65mm thick EPS composite panel/rock wool panel |
|
| EPS | 12kg/m³ | 保温防火 Insulation and fireproof |
|
| 玄武岩棉 Basalt cotton |
60kg/m³ | 保温防火棉 Insulation and fireproof cotton |
|
| 配件 Accessory |
防盗门 Entrance door (for apartment) |
970*1970 | 钢制门 Steel door |
| 塑钢窗 Moulded window |
970*970 | 单玻、纱窗、护栏 Single-glazed, screened windows, guardrails |
|
| 电路 Electrical equipment |
电器布线，严格按照防潮规范安装。根据电路工程规范连接电路，室内：进线4㎡国标软铜线插座进线2.5㎡ Electrical wiring, installed in strict accordance with the norms of moisture protection. Connect circuits according to circuit engineering specifications, indoor: incoming 4m² national standard soft copper wire socket incoming 2.5m² |
||
| 电灯控制开关 Light control switch |
3个插座，面板开关一个 3 sockets, one panel switch |
||
| 灯 Light |
灯座一个，节能灯一个 One lamp holder, one energy-saving lamp |
||
| 断路器 Interrupter |
高分断小型断路器，配漏电开关 High sectional miniature circuit breakers with earth leakage switches |
||
